Range is in red when it is more than 7 x RMS.
All measurement numbers are in microns
File 2439-10B.Lvpool.CONTOR.1579.txt analysed
|
Residuals which are more than twice the mean residual are indicated in
red
Range is in red when it is more than 7 x RMS. All measurement numbers are in microns |
|
| Edge Num | | Min Residual | | Max Residual | | Mean Residual | | RMS Residual | | Range (min-max) | | Num Points | |
| 1 | -8.90 | -3.01 | -6.06 | 1.20 | 5.89 | 114 |
| 2 | -10.42 | -4.62 | -7.44 | 0.95 | 5.8 | 122 |
| 3 | -20.68 | -6.30 | -13.18 | 4.86 | 14.38 | 7 |
| 4 | -8.21 | 17.80 | -3.84 | 1.97 | 26.01 | 490 |
| 5 | -6.97 | -0.27 | -4.44 | 1.72 | 6.7 | 25 |
| 6 | -7.32 | -2.89 | -4.50 | 1.01 | 4.43 | 24 |
| 7 | -15.15 | -8.21 | -11.16 | 1.19 | 6.94 | 346 |
| 8 | -8.63 | -1.54 | -5.37 | 1.59 | 7.09 | 344 |
| 9 | -6.01 | 1.06 | -1.86 | 1.60 | 7.07 | 344 |
| 10 | -9.55 | 1.81 | -5.23 | 1.45 | 11.36 | 343 |
| 11 | -8.04 | -1.62 | -4.20 | 1.18 | 6.42 | 344 |
| 12 | -14.41 | -9.06 | -11.49 | 1.02 | 5.35 | 344 |
| 13 | -12.64 | -1.79 | -9.66 | 1.05 | 10.85 | 344 |
| 14 | -9.52 | -1.93 | -5.27 | 1.74 | 7.59 | 351 |
| 15 | 4.10 | 7.37 | 5.57 | 0.86 | 3.27 | 18 |
| 16 | -6.88 | 2.32 | -2.52 | 1.80 | 9.2 | 526 |
| 17 | -6.81 | -4.25 | -5.83 | 0.98 | 2.56 | 4 |
| 18 | -11.92 | -5.03 | -9.53 | 1.08 | 6.89 | 129 |
| 19 | -12.03 | -8.20 | -10.18 | 0.89 | 3.83 | 102 |
| 20 | -20.39 | -11.01 | -15.06 | 1.80 | 9.38 | 356 |
| Mean | -6.56 | 1.50 | ||||
| NumPoints | 4677 | |||||
| Rot&Shift | 3.14156 | 4.15 | -2.90 | -2.97 | ||
| | | Rotation | | Total shift | | Delta x | | Delta y | |
